Specifications
| ITEM/MODEL NO. | Nominal Dimension (mm) | Opening - Top | Opening - Bottom | Opening Filling | Opening Discharging | Volume (Litre/Gallon) | Base Type |
|---|---|---|---|---|---|---|---|
| SGC 36×72 | 900×2160 | 6"-FLG | 6"-FLG | 969.2/261.7 | Tripod | ||
| SGC 06×09 | 156×223 | 2.5"–8NPSM | None | 2.5/0.6 | Standard | ||
| SGC 06×10 | 156×259 | 2.5"–8NPSM | None | 3.2/0.8 | Standard | ||
| SGC 06×13 | 156×335 | 2.5"–8NPSM | None | 5/1.3 | Standard | ||
| SGC 06×17 | 156×437 | 2.5"–8NPSM | None | 6.5/1.8 | Standard | ||
| SGC 06×18 | 156×462 | 2.5"–8NPSM | None | 7/1.8 | Standard | ||
| SGC 06×29 | 156×741 | 2.5"–8NPSM | None | 12/3.1 | Standard | ||
| SGC 06×35 | 156×894 | 2.5"–8NPSM | None | 14.8/4 | Standard | ||
| SGC 07×13 | 180×330 | 2.5"–8NPSM | None | 5.2/1.4 | Standard | ||
| SGC 07×17 | 180×422 | 2.5"–8NPSM | None | 8.3/2.2 | Standard | ||
| SGC 07×24 | 180×600 | 2.5"–8NPSM | None | 12.4/3.3 | Standard | ||
| SGC 07×30 | 180×772 | 2.5"–8NPSM | None | 16.1/4.3 | Standard | ||
| SGC 07×35 | 200×330 | 2.5"–8NPSM | None | 18.8/5.1 | Standard | ||
| SGC 07×44 | 180×1120 | 2.5"–8NPSM | None | 24.2/6.5 | Standard | ||
| SGC 08×13 | 200×338 | 2.5"–8NPSM | None | 8/2.2 | Standard | ||
| SGC 08×17 | 200×437 | 2.5"–8NPSM | None | 45964 | Standard | ||
| SGC 08×24 | 200×625 | 2.5"–8NPSM | None | 16.8/4.5 | Standard | ||
| SGC 08×35 | 200×895 | 2.5"–8NPSM | None | 25.2/6.8 | Standard | ||
| SGC 08×44 | 200×1125 | 2.5"–8NPSM | None | 32.5/8.6 | Standard | ||
| SGC 09×17 | 230×455 | 2.5"–8NPSM | None | 13.8/3.6 | Standard | ||
| SGC 09×35 | 230×900 | 2.5"–8NPSM | None | 31.1/8.4 | Standard | ||
| SGC 09×42 | 230×1073 | 2.5"–8NPSM | None | 37.8/10.2 | Standard | ||
| SGC 09×48 | 230×1225 | 2.5"–8NPSM | None | 43.7/11.6 | Standard | ||
| SGC 10×11 | 250×297 | 2.5"–8NPSM | None | 11.5/3 | Standard | ||
| SGC 10×13 | 250×336 | 2.5"–8NPSM | None | 13/3.4 | Standard | ||
| SGC 10×17 | 250×429 | 2.5"–8NPSM | None | 16.4/4.3 | Standard | ||
| SGC 10×19 | 250×494 | 2.5"–8NPSM | None | 18.8/5 | Standard | ||
| SGC 10×24 | 250×622 | 2.5"–8NPSM | None | 25/6.6 | Standard | ||
| SGC 10×28 | 250×722 | 2.5"–8NPSM | None | 25/6.6 | Standard | ||
| SGC 10×35 | 250×896 | 2.5"–8NPSM | None | 38.8/10.3 | Standard | ||
| SGC 10×44 | 250×1130 | 2.5"–8NPSM | None | 50/13.5 | Standard | ||
| SGC 10×54 | 250×1380 | 2.5"–8NPSM | None | 62.5/16.5 | Standard | ||
| SGC 10×54 | 250×1380 | 2.5"–8NPSM | 2.5"–8UN | 62.5/16.9 | Tripod | ||
| SGC 10×54 | 250×1380 | 4"–8UN | None | 62.5/16.9 | Tripod | ||
| SGC 12×36 | 300×920 | 2.5"–8NPSM | None | 55.6/14.7 | Standard | ||
| SGC 12×48 | 300×1220 | 2.5"–8NPSM | None | 77.5/20.5 | Standard | ||
| SGC 12×54 | 300×1320 | 2.5"–8NPSM | None | 85.3/22.4 | Standard | ||
| SGC 12×65 | 300×1650 | 2.5"–8NPSM | None | 108.5/28.7 | Standard | ||
| SGC 13×44 | 330×1120 | 2.5"–8NPSM | None | 81.1/21.4 | Standard | ||
| SGC 13×52 | 330×1320 | 2.5"–8NPSM | None | 102.3/27 | Standard | ||
| SGC 14×52 | 350×1320 | 2.5"–8NPSM | None | 113.5/30.5 | Standard | ||
| SGC 14×52 | 358×1320 | 4"–8UN | 4"–8UN | 113.5/30.5 | Tripod | ||
| SGC 14×65 | 358×1661 | 2.5"–8NPSM | None | 146.8/38.7 | Standard | ||
| SGC 14×65 | 350×1650 | 4"–8UN | 4"–8IN | 146.8/39.6 | Tripod | ||
| SGC 14×65 | 400×1325 | 2.5"–8NPSM | None | 150.5/39.8 | Round | ||
| SGC 16×52 | 400×1320 | 4"–8UN | 4"–8UN | 150/40.5 | Tripod | ||
| SGC 18×36 | 450×920 | 4"–8UN | None | 118.1/31.9 | Round | ||
| SGC 18×53 | 450×1350 | 4"–8UN | None | 186.5/49.3 | Round | ||
| SGC 18×65 | 450×1650 | 4"–8UN | 4"–8UN | 235/63.5 | Tripod | ||
| SGC 18×65 | 450×1873 | 4"–8UN | 4"–8UN | 235/63.5 | Tripod | ||
| SGC 18×65 | 450×1650 | 6"–FLG | 6"–FLG | 307/81.1 | Tripod | ||
| SGC 20×69 | 500×1955 | 4"–8UN | 4"–8UN | 307/82.9 | Tripod | ||
| SGC 21×36 | 550×940 | 4"-8UN | None | 164.4/44.4 | Round | ||
| SGC 21×53 | 550×1370 | 4"-8UN | None | 257.9/69.6 | Round | ||
| SGC 21×65 | 550×1804 | 4"-8UN | 4"-8UN | 409.4/108 | Tripod | ||
| SGC 24×65 | 600×1920 | 4"-8UN | 4"-8UN | 460.5/121.7 | Tripod | ||
| SGC 24×65 | 600×1980 | 6"-FLG | 6"-FLG | 460.5/121.7 | Tripod | ||
| SGC 24×72 | 600×2008 | 4"-8UN | 4"-8UN | 476/125.7 | Tripod | ||
| SGC 24×72 | 600×2140 | 6"-FLG | 6"-FLG | 476/125.7 | Tripod | ||
| SGC 30×65 | 750×1855 | 4"-8UN | 4"-8UN | 616.4/166.4 | Tripod | ||
| SGC 30×65 | 750×2062 | 6"-FLG | 6"-FLG | 616.4/166.4 | Tripod | ||
| SGC 30×72 | 750×2035 | 4"-8UN | 4"-8UN | 696.1/187.9 | Tripod | ||
| SGC 30×72 | 750×2240 | 6"-FLG | 6"-FLG | 718.9/194.1 | Tripod | ||
| SGC 30×65 | 900×1910 | 4"-8UN | 4"-8UN | 860/232.2 | Tripod | ||
| SGC 30×65 | 900×1980 | 6"-FLG | 6"-FLG | 860/232.2 | Tripod | ||
| SGC 40×65 | 1000×1950 | 4"-8UN | 4"-8UN | 1087.1/293.5 | Tripod | ||
| SGC 40×65 | 1000×2040 | 6"-FLG | 6"-FLG | 1087.1/293.5 | Tripod | ||
| SGC 40×79 | 1000×2310 | 4"-8UN | 4"-8UN | 1257.5/332.1 | Tripod | ||
| SGC 40×79 | 1000×2360 | 6"-FLG | 6"-FLG | 1257.5/332.1 | Tripod | ||
| SGC 42×72 | 1100×2180 | 6"-FLG | 6"-FLG | 1387.5/374.6 | Tripod | ||
| SGC 48×72 | 1200×2195 | 6"-FLG | 6"-FLG | 1751.3/462.7 | Tripod | ||
| SGC 48×94 | 1200×2400 | 6"-FLG | 6"-FLG | 1910.1/504.6 | Tripod | ||
| SGC 60×79 | 1500×2425 | 6"-FLG | 6"-FLG | 3011/813 | Tripod | ||
| SGC 63×72 | 1600×2110 | 6"-FLG | 6"-FLG | 2629.8/694.8 | Tripod | ||
| SGC 63×86 | 1600×2460 | 6"-FLG | 6"-FLG | 3424.5/924.6 | Tripod | ||
| SGC 72×72 | 1800×2060 | 6"-FLG | 6"-FLG | 4610/1217.4 | Tripod | ||
| SGC 80×79 | 2000×2600 | 6"-FLG | 6"-FLG | 5172/1396.4 | Tripod | ||
| SGC 30×65 | 750×1855 | 4"-8UN | 4"-8UN | 4"-FLG | 4"-FLG | 616.4/166.4 | Tripod Base |
| SGC 30×72 | 750×2035 | 4"-8UN | 4"-8UN | 4"-FLG | 4"-FLG | 696.1/187.9 | Tripod Base |
| SGC 30×65 | 750×2060 | 6"-FLG | 6"-FLG | 4"-FLG | 4"-FLG | 616.4/166.4 | Tripod Base |
| SGC 30×72 | 750×2240 | 6"-FLG | 6"-FLG | 4"-FLG | 4"-FLG | 696.1/187.9 | Tripod Base |
| SGC 36×65 | 900×1910 | 4"-8UN | 4"-8UN | 4"-FLG | 4"-FLG | 860/232.2 | Tripod Base |
| SGC 36×65 | 900×1980 | 6"-FLG | 6"-FLG | 4"-FLG | 4"-FLG | 860/232.2 | Tripod Base |
| SGC 30×72 | 900×2090 | 4"-8UN | 4"-8UN | 4"-FLG | 4"-FLG | 969.2/261.7 | Tripod Base |
| SGC 36×72 | 900×2160 | 6"-FLG | 6"-FLG | 4"-FLG | 4"-FLG | 969.2/261.7 | Tripod Base |
| SGC 40×65 | 1000×1950 | 4"-8UN | 4"-8UN | 4"-FLG | 4"-FLG | 1087.1/293.5 | Tripod Base |
| SGC 40×65 | 1000×2040 | 6"-FLG | 6"-FLG | 4"-FLG | 4"-FLG | 1087.1/293.5 | Tripod Base |
| SGC 40×79 | 1000×2310 | 4"-8UN | 4"-8UN | 4"-FLG | 4"-FLG | 1257.5/332.1 | Tripod Base |
| SGC 40×79 | 1000×2360 | 6"-FLG | 6"-FLG | 4"-FLG | 4"-FLG | 1257.5/332.1 | Tripod Base |
| SGC 42×72 | 1100×2180 | 6"-FLG | 6"-FLG | 4"-FLG | 4"-FLG | 1387.5/374.6 | Tripod Base |
| SGC 48×72 | 1200×2195 | 6"-FLG | 6"-FLG | 4"-FLG | 4"-FLG | 1751.3/462.7 | Tripod Base |
| SGC 48×94 | 1200×2400 | 6"-FLG | 6"-FLG | 4"-FLG | 4"-FLG | 1910.1/504.6 | Tripod Base |
| SGC 60×79 | 1500×2425 | 6"-FLG | 6"-FLG | 4"-FLG | 4"-FLG | 3011/813 | Tripod Base |
| SGC 63×72 | 1600×2110 | 6"-FLG | 6"-FLG | 4"-FLG | 4"-FLG | 2629.8/694.8 | Tripod Base |
| SGC 63×86 | 1600×2460 | 6"-FLG | 6"-FLG | 4"-FLG | 4"-FLG | 3424.5/924.6 | Tripod Base |
| SGC 72×72 | 1800×2060 | 6"-FLG | 6"-FLG | 4"-FLG | 4"-FLG | 4610/1217.4 | Tripod Base |
| SGC 80×79 | 2000×2600 | 6"-FLG | 6"-FLG | 4"-FLG | 4"-FLG | 5172/1396.4 | Tripod Base |
